UltraLAN SFP+ Module - MM 10G 300m 850nm
UltraLAN SFP+ Module - MultiMode 10G 300m 850nm
UltraLAN's FIB-SFP-ULSP851XL-CDS3 Enhanced Small Form Factor Pluggable SFP+ transceivers are designed for use in 10-Gigabit Ethernet over MultiMode fiber. They are compliant with SFF-8431,SFF-8432 and IEEE 802.3ae 10GBASE-SR/SW.
The transceiver designs are optimized for high performance applications while remaining cost effective to supply customers the best solution for telecommunication and data center installations.
- Supports up to 11.3Gb/s bit rates
- Duplex LC connector
- Hot pluggable SFP+ footprint
- 850nm VCSEL transmitter, PIN photo-detector
- Up to 300m on 50/125um MMF(2000MHZ.KM)
- Low power consumption, < 1W
- Digital Diagnostic Monitor Interface
- Optical interface compliant to IEEE 802.3ae
- Electrical interface compliant to SFF-8431
UltraLAN Part Code Matrix:
